5G NR/LTE/WCDMA多种制式
? Sub-6GHz
? 独立组网SA和非独立组网NSA
? 使用于视频采集、VR、4K/8K电视等场景
| 基本特性 | Dimension(mm):30.00 x 52.00 x 2.3 Package:M.2 LTE:Cat 20 and above LTE FDD:B2/B4/B5/B7/B12/B13/B14/B17/B25/B26/B29/B30/B66/B71 LTE TDD:B41/B42/B43**/B48 WCDMA:B1/B2/B4/B5/B8 Operation mode:NSA & SA Antenna:4 Power Supply:3.3V~4.4V(Typical 3.8V) Operating Temp.:-30℃~+75℃ | |
接口 | PCIe:PCIe 3.0 USB3.1:x 1 GPIO:■ I2C:■ UIM:■ I2S:■ MIPI:■ | |
认证 | HF*/FCC*/GCF*/PTCRB*/TMO*/Verizon*/AT&T* | |
| 关键功能 | NR MIMO: DL 4 x 4 MIMO: n2, n66, n41,n78 UL 1 x 1 MIMO LTE MIMO: DL 4 x 4 MIMO: B2, B4 ,B7, B25, B30, B41, B42, B46, B66, B48 UL 1 x 1 MIMO Downlink: NR sub6: 4 x 4 MIMO 256QAM 1CC(4 layers) LTE: 4 x 4 MIMO 1024QAM 7CC(6CC 24 layers) Downlink: NR sub6: 2 x 2 MIMO 256QAM LTE: 1 x 1 MIMO 256QAM | |
| 功能 | Voice:VoLTE SMS:SMS over IP(IMS) Audio:■ FOTA:■ OS Drivers:Linux 4.1**/Android 9.0** GNSS:GPS/GLONASS/Galileo/Beidou |
